-32%
45.00€ 65.90€
| Specification | |
| Performance Parameters | |
| Light Sources | (Aimer)RED color LED, (lllumination)White color LED |
| Supported Symbologies | ID: Codabar, Code 39, Code 32 Pharmaceutical(PARAF), Interleaved 2 of 5,NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA,
Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8,EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited,GS1 DataBar Expanded, China Post(Hong Kong 2 of 5), Korea Pos. |
| Image (Pixels) | 640pixels (H) x 480 pixels (V) |
| Field of View: | 39°(Horizontal), 29°(Vertical) |
| Print Contrast: | 20% minimum reflective difference |
| Motion Tolerances: | > 1m/s |
| Scan Angle | Yaw±65°, Rotation 360°, Pitch±65° |
| Depth of scan field | Code39(5mil): 7-16cm, Code39(13mil): 7-32cm
QR code (15mil): 3-18cm, Codel28(20mil): 6-35cm |
| Error Rate | 1/5million |
| Interface | USB,USB-COM,RS232 |
| Physical Parameters | |
| Dimensions | 83.5mm*65.7mm*174.8mm |
| Material | ABS+PC |
| Cable Length | 1.8M |
| Environmental Parameters | |
| Operating Temperature | -20℃ ~60℃ |
| Storage Temperature | -30℃~70℃ |
| Relative Humidity | 5%~95% RH（Non-condensing） |
| Ambient lighting | 0~100000LUX |
| Electronic Parameters | |
| Working Voltage | DC5V±5% |
| Operating Current | 300mA |
| Standby Current | 35mA |
| Βάρος | 0.50 kg |
|---|
